Product Description
Main raw materials：Fresh and healthy beef bones
Characteristic：Taste masking, beautiful, easy to swallow, high bioavailability. Meanwhile, it has the advantages of accurate dose, easy to carry and use, and safe sealing.
Size: 0#, 1#, 2#, 3#, 4#, 5#,00#,000#
Color: Opaque, Clear, and customized colors
Printing: Linear, Circular printing
Status of Capsule: 3 years generally, 5 years available
Technical Specification of Gelatin Hollow Capsule
Size of Capsules | Length of Capsule Parts | External Diameter | Overall Closed Length(mm) | Average Weight | Weight Tolerance | |
00# | Cap | 10.7~10.9 | 8.39~8.49 | 22.2~23.2 | 86.2~94.3 | ± 6% |
Body | 11.3~11.5 | 8.05~8.15 | ||||
0# | Cap | 10.9~11.1 | 7.53~7.63 | 20.7~21.7 | 98.0~106.4 | ± 6% |
Body | 18.4~18.6 | 7.23~7.33 | ||||
1# | Cap | 9.7~9.9 | 6.81~6.91 | 18.5~19.5 | 75.8~82.0 | ± 6% |
Body | 16.4~16.6 | 6.53~6.63 | ||||
2# | Cap | 8.9~9.1 | 6.25~6.35 | 17.0~17.8 | 64.9~69.4 | ± 6% |
Body | 15.3~15.5 | 5.97~6.07 | ||||
3# | Cap | 8.0~8.2 | 5.73~5.83 | 15.0~15.8 | 50~52.6 | ± 8% |
Body | 13.3~13.5 | 5.47~5.57 | ||||
4# | Cap | 7.1~7.3 | 5.27~5.37 | 13.4~14.3 | 38.4~40 | ± 8% |
Body | 12.1~12.3 | 5.00~5.10 | ||||
Features of Gelatin Hollow Capsule
1. Only Pharmaceutical Grade Bone Gelatin used, BSE/TSE Free.
We have gained ISO 9000, HACCP ,DMF,KOSHER,FDA etc.
2. Filling rate of empty capsules is always higher than 99.0%, and can reach 99.7%.
Quality Control in Capsule Production
Gelatin undergoes stringent preliminary physical, chemical and micro-biological inspections before released into production.
Capsules are manufactured under controlled climate conditions (Class 100,000), using a dipping process on automatic capsules manufacturing machines.
Quality Assurance plays an integral part in monitoring all critical process parameters like temp and humidity, measurable parameters like weight, length etc. . It eliminates error in every stage of production to meet customer requirement / satisfaction.
A thorough inspection and continuous monitoring of critical process and measurable parameters provides Zero Defect Capsules.
Specification of Empty Capsules
Items | Results |
Elastic Tightness | Less than 1pcs |
Friability | Less than 5pcs |
Disintegration Time | Less Than 10 Minutes |
Loss on Drying | 12.5-17.5% |
Residue after Ignition (%) | Transparent: ≤2 |
Heavy Metals (ppm) | ≤40 |
Viscosity (mm2/s) | ≥60 |
Micro-Organism | Total count of Bacillus: ≤1000unit/g, |
Production Process:
Colors available:
Packing:
Refrigerated container is recommended for delivery of empty capsules.
147 cartons in one 20’ container.
342 cartons in one 40’ container.
Storage of empty capsules
Temp: 15º C to 25º C
Humidity: 35% to 65%
Packing:polybag+Aluminum foil+foam board+carton box(size:60*41*74.5cm) | |||||||||
Size | Qty | N.W | G.W | Weight | Volume | Capacity | |||
0.6g/(ml) | 0.8g/(ml) | 1.0g/(ml) | 1.2g/(ml) | ||||||
00# | 70,000 | 8.5 | 11.5 | 122+/-10 | 0.79 | 444mg | 592mg | 740mg | 888mg |
0# | 100,000 | 10 | 13 | 97+/-8 | 0.67 | 408mg | 544mg | 680mg | 816mg |
1# | 140,000 | 11 | 14 | 77+/-6 | 0.5 | 300mg | 400mg | 500mg | 600mg |
2# | 180,000 | 11 | 14 | 62+/-5 | 0.37 | 222mg | 296mg | 370mg | 444mg |
3# | 240,000 | 12 | 15 | 49+/-4 | 0.3 | 180mg | 240mg | 300mg | 360mg |
4# | 300,000 | 12 | 15 | 39+/-3 | 0.21 | 126mg | 168mg | 210mg | 252mg |
Advanced Equipment:
GMP Workshop
Certificates:
